MEMS Gyroscopes

Gladiator Technologies Low Noise MEMS Gyroscopes are designed for stabilization applications. Choose from high speed digital Triaxial Gyros or Single Axis Analog, suitable for a variety of stabilization applications that benefit from low noise sensors, high speed outputs and fully calibrated gyroscopes.

Low Noise Gyroscopes

Gladiator designs every one of our gyroscopes with low noise MEMS sensors. Low noise is critical to precision measurement. Gladiator products deliver exceptional noise performance in a SWaP-C package.

High Speed

Speed matters. Our products are built to output data at lightning fast data rates with reduced phase lag. Products can be enabled with up to 10 kHz data rates and 600 Hz Bandwidth without compromising inertial performance.

MISSION QUALIFIED

Gladiator gyroscopes have been utilized for the most challenging applications. Our high performance gyroscopes are field proven and meet the demands required of a tactical grade inertial system.

G300D Triaxial Gyroscope

G300D Triax Gyroscope

The new, SX2 G300D is Gladiator Technologies’ high speed, three-axis MEMS gyroscope equipped with low noise sensors, VELOX™ high speed processing and user configurable firmware. At only 0.6 cubic inches, the G300D gyro comes factory calibrated over the full temperature range, conditioned over environments and is ideal for precision stabilization and rotation measurement applications.

0.6

Cubic Inches

0.0017°/s/√Hz

ARW

0.075°/s

Bias Over Temperature

600 Hz

Bandwidth

10 kHz

Data Rates

20 µs

Message Delay

NEED MORE INFORMATION?

G200 Dual Axis Gyroscope

The G200 is Gladiator Technologies’ high speed, two-axis MEMS gyroscope equipped with ultra low noise sensors. At only 0.6 cubic inches, the G300D gyro comes factory calibrated over the full temperature range, conditioned over environments and is ideal for precision stabilization and rotation measurement applications.

.5

Cubic Inches

0.003°/sec/√Hz

ARW

<0.0028°/sec

Short Term Bias Stability

200 Hz

Bandwidth

500g

Shock

4.75

Voltage Reference

G150Z Single Axis Gyroscope

G150Z Gyroscope MEMS
The G150Z Analog MEMS Gyroscope is a small, ultra-fast, single axis gyro featuring low noise MEM’s sensors. This environmentally sealed gyro is rated for 500g shock and 6g RMS vibration. The G150Z’s analog output voltage is ±4.75 volts and it is available in three rate ranges. Applications include stabilization, flight control, navigation and automotive testing.

1.1

Cubic Inches

0.001°/sec/√Hz

ARW

1.2°/h

Short Term Bias Stability

200 Hz

Bandwidth

500g

Shock

4.75

Voltage Reference

Product Applications

PLATFORM STABILIZATION

EO/IR Applications



GIMBAL STABILIZATION
