MEMS Accelerometers

Gladiator Technologies Low Noise MEMS Accelerometers are ideal for precision measurement applications. Choose either our three-axis digital or single-axis analog accelerometer depending on your specific application needs.

Low Noise

Gladiator designs every one of our accelerometers with low noise MEMS sensors. Low noise is critical to precision measurement. Gladiator products deliver exceptional noise performance in a SWaP-C package.

High Speed

Speed matters. Our products are built to output data at lightning fast data rates with reduced phase lag. Products can be enabled with up to 10 kHz data rates and 600 Hz Bandwidth without compromising inertial performance.

MISSION QUALIFIED

Gladiator accelerometers have been utilized for the most challenging applications. Our high performance accelerometers are field proven and meet the demands required of a tactical grade inertial system.

GA50 Single Axis, MEMs Accelerometer

GA50-070-100 Open Loop MEMS Accelerometer

The GA50 series high-end open loop MEMS accelerometers are available in various sensing ranges. The accelerometer is based on a bulk micro-machined silicon MEMS device and an application-specific integrated circuit (ASIC) with an analog front end (AFE) and a temperature sensor, assembled in a custom tailored, hermetically sealed, and compact LCC20 package.

Multiple G Ranges: ±5, ±40, ±70

Excellent Long Term Bias Repeatability

Nav-Grade Short Term Stability

Nav-Grade Ultra-Low VRW Noise

Low Scale Factor

Evaluation Board Mounted Accels Available to Verify Performance

A300D three-axis MEMS accelerometer

A300D Accelerometer

The new A300D is Gladiator Technologies’ ultra-low noise three-axis digital MEMS accelerometer with high dynamic range sensors. At only 0.6 cubic inches, the A300D accelerometer comes factory calibrated over the full temperature range, conditioned over environments.

±40 g

Sensor Range

0.058 mg /√Hz

VRW

0.5 mg

Bias Over Temperature

44µs

Message Delay

0.6

Cubic Inches

800Hz

Bandwidth

NEED MORE INFORMATION?

A40 Single-Axis MEMS Accelerometer

A40 Accelerometer
The A40 Accelerometer is a small, ultra-low noise, single-axis analog MEMS accel. This robust accel is designed to handle 500g shock and 5.74g RMS vibration in an EMI resistant housing. Its price and performance are ideal for low frequency motion and tilt measurement.
0.7 mg

 Bias Repeatability

0.065mg/√Hz
VRW
140 Hz
Bandwidth
2.5 VDC
Analog Output

500g

Shock Tolerance

0.8

Cubic Inches

Product Applications

Unmanned Aerial Vehicles

Transportation

High Dynamic IMU

Defense
